2-Piece Flanged Ball Valve

Description

The 2-Piece Flanged Ball Valve is designed for high-capacity industrial and municipal piping systems where threaded connections are not practical. The flanged ends allow for secure, high-pressure bolting between pipe sections, making it significantly easier to install, inspect, or replace these valves in large-diameter lines (DN50 and above). The 2-piece body construction provides a robust, monolithic structure capable of handling the high-pressure demands of modern pumping and distribution networks.

Technical Specifications

• Design Type: 2-Piece Bolted Body, Full Bore

• Connection: Flanged (ASME B16.5 / DIN / PN16 / PN40)

• Operation: Lever or Gearbox (depending on size)

• Body Material: Stainless Steel (SS316 / CF8M) or Carbon Steel (WCB)

• Sealing: PTFE/RTFE seats for industrial durability

• Pressure Rating: Class 150 / PN16 / PN40

• Features: Anti-blowout stem, ISO mounting pad for automation

Key Applications

• Municipal Water Distribution: The standard shut-off valve for main water lines and pumping stations.

• Large-Scale Manifolds: Essential for distributing fluids across multiple process units in Ras Laffan and Mesaieed.

• Chemical & Petrochemical: Robust sealing ensures safety in hazardous media lines.

• HVAC/Chilled Water: Ideal for large chiller plant distribution loops where minimizing pressure drop is critical.
